52 DC motor standard type

1、 Product features:

1. Efficient DC drive

-Adopting brushed DC motor, it runs smoothly, has low noise (≤ 45dB), and is energy-saving and efficient.

-Support WM speed regulation or potentiometer speed regulation (depending on the model) to meet the speed requirements of different scenarios.

2. Compact tubular design

-The shell is made of aluminum alloy material, lightweight and has good heat dissipation, with a protection level of IP44-67 (dustproof and waterproof).

-Diameter 52mm, compact structure, suitable for concealed installation or narrow spaces.

3. High precision control

-Built in Hall sensor or encoder (optional) for precise position feedback, with a repeat positioning accuracy of ± 0.1mm.

-Optional limit switch or programmable controller, supporting customized travel.

4. Wide compatibility

-Compatible with multiple power sources (12V/24V DC), supporting connection with solar energy systems, battery packs, or standard power sources.

-Interface standardization (optional RS485, CAN bus, or wireless remote control) facilitates the integration of smart home/industrial systems.

5. Safe and reliable

-Overload protection, overheating protection, and locked rotor protection functions extend the lifespan of the motor.

-Low voltage startup (≥ 9V), manual emergency operation can be performed after power failure (some models).

2、 Application scenarios

1. Smart home: electric curtains, lifting cabinets, projection screen drive.

2. Medical equipment: bed adjustment, operating table lifting.

3. Industrial automation: assembly line push rods, valve control, small robotic arms.

4. Outdoor facilities: solar tracking brackets, agricultural greenhouse windows.
